Bearing Systems: Dual Ceramic Ball Bearing

Compressor Wheel: 71*88mm

Turbine Wheel: 77*70mm

Compressor Inlet: 4″ Hose

Compressor Outlet: 2.5″ Hose

Turbine Inlet: V-band or T4 divided

Turbine Outlet: 3.5”or 4″ V-band (see details after housing selection)

Water Ports: -6AN

Oil Feed(excl’): Flange Required(Recommended size: -4AN Std T4 Flange )

Oil Drain: -12AN(O-Ring sealed Flange Kit Incl’)

Turbine Housing Options: T4(Divided) 0.95 A/R, 1.06 A/R, Dual V-band 1.06A/R

Related Products: Oil Feed Flange Kit: 912357001 | -4AN ∅ 1.65mm (0.065″) Orifice
